Short-length Multi-walled carbon nanotubes (MWCNT)：
Product Code : TNSM1, TNSMH1, TNSMC1
Technical Data (pdf)
Product Description:
Timestub
TM --Short-length High purity Multi-walled carbon nanotubes---have three kinds of products: TNSM1, TNSMH1 and TNSMC1.TNSM1 is produced by mechanical cutting TNM1, followed by dis-agglomeration treatment. TNSMH1 and TNSMC1 are the TNSM1 hydroxyl and carboxyl functionalized products, respectively. TNSMH1 and TNSMC1 are prepared by KMnO
4 oxidation in H
2SO
4 solution at different temperature and different KMnO
4 concentration.
| Property |
Unit |
Short-Length MWCNTs |
Method of Measurement |
| TNSM1 |
TNSMH1 |
TNSMC1 |
| OD |
nm |
5-15 |
5-15 |
5-15 |
HRTEM,Raman |
| Purity |
wt% |
>98 |
>98 |
>98 |
TGA & TEM |
| Length |
microns |
0.5-2 |
0.5-2 |
0.5-2 |
TEM |
| SSA |
m2/g |
>270 |
>270 |
>270 |
BET |
| ASH |
wt% |
<2 |
<2 |
<2 |
TGA |
| Ig/Id |
-- |
-- |
-- |
-- |
Raman |
| -OH Content |
wt% |
|
5.58 |
|
XPS & Titration |
| -COOH Content |
wt% |
|
|
3.86 |
XPS & Titration |
| OD=Outer Diameter ID=Inner Diameter SSA=Specific Surface Area |
