Aligned Multi-walled carbon nanotubes (TNAIM):
Product Code:TNAIM
|
Technical Data of TNAIM (pdf) ( Download )
|
|
Property |
Unit |
Aligned MWCNTs |
Method of Measurement |
|
TNAIM |
|||
|
OD |
nm |
8-15 |
HRTEM,Raman |
|
Purity |
wt% |
>98 |
TGA & TEM |
|
Length |
microns |
30-50 |
TEM |
|
SSA |
m2/g |
200-250 |
BET |
|
ASH |
wt% |
<2 |
TGA |
|
Ig/Id |
-- |
-- |
Raman |
|
OD=Outer Diameter ID=Inner Diameter SSA=Specific Surface Area |
|||
